效果图:
<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8">
<title>Echars柱状图嵌套 </title>
<style type="text/css">
body{
height: 100%;
width: 100%;
background-color: #0a3b76;
}
</style>
</head>
<body>
<div style="width: 100%;height: 400px;" id="echarts"></div>
</body>
<script src="https://cdnjs.cloudflare.com/ajax/libs/echarts/5.3.2/echarts.min.js" type="text/javascript" charset="utf-8"></script>
<script type="text/javascript">
echars()
function echars() {
let xAxis = ['08:00~09:00', '09:00~10:00', '10:00~11:00', '11:00~12:00', '12:00~13:00', '13:00~14:00',
'14:00~15:00', '15:00~16:00', '16:00~17:00', '17:00~18:00', '18:00~19:00',
'19:00~20:00'
]
var dl1 = [];
var dl2 = [];
var dl3 = [];
for (let item of xAxis) {
dl1.push(750 * 2)
dl2.push(750)
dl3.push(parseInt(Math.random() * 300 + 600))
}
var legend = ["小时目标数", "当前目标数", "实际产出"];
let color = [
['rgba(255,255,255,0.4)', '#00cbff', '#a5d6a7'],
['rgba(255,255,255,0.4)', '#00cbff', '#4caf50']
]
//定义两个上下箭头的矢量路径
let myChart = echarts.getInstanceByDom(document.getElementById('echarts'));
if (myChart === undefined) {
myChart = echarts.init(document.getElementById('echarts'));
};
// 显示标题，图例和空的坐标
myChart.showLoading({
text: 'loading',
color: '#19ecff',
textColor: '#fff',
maskColor: 'rgba(58, 186, 255, 0.1)',
zlevel: 0,
}); //数据加载完之前先显示一段简单的loading动画
var option = {
title: {
text: "产出",
textStyle: {
//文字颜色
color: '#fff',
fontSize: 18
}
},
tooltip: {
trigger: 'axis',
backgroundColor: 'rgba(42, 47, 53, 0.9)',
borderColor: '#ffffff',
textStyle: {
color: "#fff"
},
axisPointer: {
lineStyle: {
color: '#fff'
}
},
formatter: function(params) {
let html = "";
html = params[0].name + '<br>';
for (let i = 0; i < params.length; i++) {
html +=
'<span style="display:inline-block;margin-right:5px;border-radius:10px;width:10px;height:10px;background-color:' +
params[i].color.colorStops[0].color + ';"></span>'
html += params[i].seriesName + " : " + params[i].value + " PCS<br>";
}
return html;
},
},
legend: {
data: legend,
top: "0%",
x: 'center', //居右显示
// right: '3%',
textStyle: {
"color": "rgba(255,255,255,0.9)" //图例文字
}
},
grid: {
containLabel: true,
left: '3%',
right: '3%',
bottom: '4%',
top: '25%',
},
xAxis: [{
axisLabel: {
color: '#fff',
fontSize: 14,
interval: 0,
formatter: function(value) {
value = value.replace(/~/g, "");
var ret = ""; //拼接加\n返回的类目项
var max = 5; //每行显示的文字字数
var val = value.length; //X轴内容的文字字数
var rowN = Math.ceil(val / max); //需要换的行数
if (rowN > 1) { //判断 如果字数大于2就换行
for (var i = 0; i < rowN; i++) {
var temp = ""; //每次截取的字符串
var start = i * max; //开始截取的位置
var end = start + max; //结束截取的位置
temp = value.substring(start, end) + "\n";
ret += temp; //最终的字符串
}
return ret;
}
return value
}
},
axisTick: {
show: true, // 隐藏坐标轴的刻度线
alignWithLabel: true, // 图形于标题居中
},
splitLine: {
show: false,
},
axisLine: {
show: false
},
data: xAxis,
type: 'category',
},
{
type: 'category',
axisLine: {
show: false
},
axisTick: {
show: false
},
axisLabel: {
show: false
},
splitArea: {
show: false
},
splitLine: {
show: false
},
data: xAxis
},
{
type: 'category',
axisLine: {
show: false
},
axisTick: {
show: false
},
axisLabel: {
show: false
},
splitArea: {
show: false
},
splitLine: {
show: false
},
data: xAxis
},
{
type: 'category',
axisLine: {
show: false
},
axisTick: {
show: false
},
axisLabel: {
show: false
},
splitArea: {
show: false
},
splitLine: {
show: false
},
data: xAxis
}],
yAxis: {
type: "value",
name: "数量(PCS)",
axisLabel: {
"show": true,
formatter: function(param) {
let value = (param / 1000).toFixed(1);
return value;
}
},
axisTick: {
show: true, // 隐藏坐标轴的刻度线
alignWithLabel: true, // 图形于标题居中
},
axisLine: {
show: false,
lineStyle: {
color: '#ffffff'
}
}, //右线色
splitLine: {
show: false,
lineStyle: {
color: "#b0c1d0"
}
}, //x轴线, //左线色
},
series: [
{
name: legend[0],
data: dl1,
type: 'bar',
barWidth: '40%',
barGap: 0,
xAxisIndex: 0,
itemStyle: {
normal: {
color: {
type: "linear",
x: 0,
y: 0,
x2: 0,
y2: 1,
colorStops: [{
offset: 0,
color: color[0][0]
},
{
offset: 1,
color: color[1][0]
}
],
globalCoord: false
}
}
},
label: {
normal: {
show: false,
position: "inside",
textStyle: {
color: "#fff",
fontSize: 10
}
}
},
},
{
name: legend[1],
data: dl2,
type: 'bar',
barWidth: '30%',
barGap: 0,
xAxisIndex: 1,
itemStyle: {
normal: {
color: {
type: "linear",
x: 0,
y: 0,
x2: 0,
y2: 1,
colorStops: [{
offset: 0,
color: color[0][1]
},
{
offset: 1,
color: color[1][1]
}
],
globalCoord: false
}
}
},
label: {
normal: {
show: false,
position: "inside",
textStyle: {
color: "#fff",
fontSize: 10
}
}
},
},
{
name: legend[2],
data: dl3,
type: 'bar',
barWidth: '20%',
barGap: 0,
xAxisIndex: 2,
itemStyle: {
normal: {
color: {
type: "linear",
x: 0,
y: 0,
x2: 0,
y2: 1,
colorStops: [{
offset: 0,
color: color[0][2]
},
{
offset: 1,
color: color[1][2]
}
],
globalCoord: false
}
}
},
label: {
normal: {
show: false,
position: "inside",
textStyle: {
color: "#fff",
fontSize: 10
}
}
},
},
{
name: legend[2],
data: dl3,
type: 'bar',
barWidth: '20%',
barGap: 0,
xAxisIndex: 3,
itemStyle: {
normal: {
color: {
type: "linear",
x: 0,
y: 0,
x2: 0,
y2: 1,
colorStops: [{
offset: 0,
color: color[0][2]
},
{
offset: 1,
color: color[1][2]
}
],
globalCoord: false
}
}
},
label: {
show: true,
position: ['120%',-11],
color: '#DB5E6A',
backgroundColor: {
image: icon
},
formatter: function(params) {return ""},
padding: [15, 15, 8, 5],
},
}
]
};
myChart.hideLoading(); //隐藏加载动画
myChart.clear();
myChart.setOption(option, true);
}
</script>
</html>
